Review: Yamaha CL 5

Yamaha’s CL series sounds better than any digital Yamaha before it, and is let off the leash by Australia’s own Dante networking. Power user Trevor Cronin gets into the nitty gritty details that make the CL a huge step forward.

By

20 August 2012

Review: Trevor Cronin

Over 25 years ago Yamaha became one of the pioneers of digital audio, with the DMP7 being its first digital mixer. It has since offered the pro audio world a vast array of popular digital mixing consoles. The Yamaha PM5D large format mixing console has been an industry standard for many years along with the smaller M7CL, LS9 and 01V live mixers and the O2R and DM series studio consoles. The all new CL series fits in somewhere between the PM5D and the M7CL, and depending on what configuration is purchased, it can far exceed the capability and functionality of both machines.

THE PACKAGE DEAL

This is a complete audio interface and mixing system that allows for the full range of audio-related input, control, manipulation, storage, output and distribution of audio signals required for current live sound systems. It’s a very powerful package, combining technologies from many of the leading players in the professional audio world with Yamaha’s own wealth of leading technologies and manufacturing. New for Yamaha, the system uses the Australian-developed Dante digital audio network as standard for passing audio in and out of the system, with remote stage boxes and other devices connected via Cat5 cables. It’s a big move to discard their commitment to using their own ‘Ethersound’ system on this new product. Obviously they figure that Dante is the best system currently available.

The new console sticks with the existing Centralogic user interface with a touch screen not dissimilar to the M7CL model, featuring a bigger and better viewing area and much faster operation. The fader name display is now large and fully customisable with colours (a little like a Midas), and feature an encoder for gain, pan, etc. Continuing with the existing Yamaha standard, three mini YGDAI card bays are included for connection of a large range of interfaces.

Yamaha and Lab.gruppen have teamed up to allow Lake Processing (another Australian developed technology) on the new MY8-LAKE expansion card. The card provides 8-in/8-out Mesa system EQ, 4-in/12-out Contour speaker crossover, and 4-in/4-out and 2-in/6-out Mesa and Contour combination modes. The Mesa EQ can also be used on input sources. The Lake Controller application running on a computer allows full access and management of Lake, and compatibility with Smaart Live analysing and speaker tuning software. There is also a new Dugan Designs automatic microphone mixer card (MY-16). Check out the Yamaha website for available cards. www.yamahaproaudio.com

ON STAGE WITH RIO

The CL relies mainly on Rio external stage boxes for its connections. These are all new items with newly designed (and better sounding) digitally controlled microphone preamplifiers that have a handy new gain sharing feature that allows two or more consoles to adjust the head amp gain without affecting each other’s settings — so no more arguments between front of house, monitors and broadcast engineers.

Two options are available: the 5U size Rio3224D provides 32 ins, 16 outs, and four AES/EBU digital outputs, and the 3U size Rio1608D has 16 ins and 8 outs but no AES. Up to eight units can be connected to the console. Via console control you can flash LEDs on the boxes to show which box or channel needs to be patched. No doubt there will be some new products to supplement these two models in the future with different input and output options. Being Dante you can use the Rio boxes with any other Dante system, or Ethernet enabled computer. Add Dante cards to your PM5D and use the Rio units, or hook up a computer to a Rio3224D for a very small and practical 32-in/16-out recording system.

NEED TO KNOW

Yamaha CL 5
Digital Live Sound Mixing System
  • PRICE

    CL5 Tourpack (CL5, roadcase, 2 x Rio3224D) — $50,500 (RRP)
    CL5 — $30,000
    CL3 — $27,500
    CL1 — $19,700
    MBCL — $1500
    Rio3224D — $9500
    Rio1608D — $6000

  • CONTACT

    Yamaha Commercial Audio: (03) 9693 5272 or [email protected]

  • PROS

    • New head amps sound great Dante networking hugely flexible
    • 64-track Nuendo hard disk recording
    • Lake speaker processing card
    • Centralogic user interface a breeze

  • CONS

    • No console external video connection (some people need a bigger screen)
    • No digital input on console rear or on Rios
    • Requires network switch for Dante redundancy

  • SUMMARY

    Yamaha’s CL series of digital live mixing systems are a huge leap forward. They sound great, Dante networking allows huge channel counts and recording over Ethernet, and Yamaha has built up some top outboard emulations.

The smaller format CL3 with optional meter bridge

CENTRALOGICAL IN USE

At this stage there are three consoles available — CL1, CL3 and CL5. I managed to get my hands on the largest model, the CL5, at a trade show in dusty Dubai for many hours over two days, then more recently at the CL console seminar. Although I didn’t mix a real live show I did get to know the machine by mixing a variety of pre-recorded live shows via the Nuendo multitrack input and by testing out some microphones. The CL5 package can have a maximum of 72 mono inputs and 40 outputs, and features 34 faders. For monitor mixing duties you can configure 32 mixes (24 mix and 8 matrix busses) all with output EQ.

The console interface will feel comfortable to users of other Yamaha mixers due to the continued use of the Centralogic interface, which is also where the console gets its name — CL = Central Logic. For users new to Yamaha, it’s laid out in a way that should offer little difficulty getting your head around how it all works. There are enough knobs, buttons, faders and meters to use before needing to touch the screen. Build quality is superb, using a strong one-piece aluminium extrusion, which is quite an impressive piece of engineering.

Internally the system uses the Yamaha operating system and features all new DSP along with new faster and higher capacity electronics. This makes the CL more powerful and energy efficient compared to previous models. There are plenty of great new features to make the life of live sound engineers just that bit easier.

LIVE RECORDING

Record and playback from a USB key is a great Yamaha feature that has again been included in this unit. It is only in ‘lo-fi’ MP3 (or WMA/ACC) format, so fine for the intro music and a quick recording for reference. For higher quality recordings a PC or Mac computer with Dante network drivers can run the included Steinberg Nuendo ‘Live’ multi-track hard disk system for show recording and virtual sound check/general playback.

No extra interface is required as Dante uses the computer’s high-speed network port for bi-directional transfer. More than one computer can be used at the same time — such a great feature for critical live recordings or playback.

The Integration of Steinberg’s Nuendo using Dante is a fantastic feature, it allows for state-of-the-art recordings for very little extra cost (making mobile recording companies redundant?). Steinberg is now owned by Yamaha and the console features a slightly stripped down version of Nuendo that can handle 64 inputs and 64 outputs. Tracks are automatically named from the console inputs and there is a 60-second pre-record function, so you don’t miss the start of the show! Any ASIO-compatible recording software can also be used if you prefer, or a standalone recorder such as the JoeCo Black Box with Dante interface.

COMPUTER LINK

Superseding the Studio Manager software, the all new on/off-line editing and configuration software is much easier to set up, it requires no troublesome extra driver and goes online nearly instantly. There is a new file converter so you can convert PM5D/M7CL/LS9 show files for use on the CL. Wireless remote control of the console is really easy with the iPad application, with iPad and editor control of the system able to both work at the same time. Smaller shows and static setups will no longer need an extra console for monitoring if there is someone knowledgeable in the band with good ears and an iPad. Overall it’s a really well sorted integration with external computers, well done Yamaha.

The smallest model (CL1) weighs under 32kg in a flight case, so is able to be put on an aircraft as checked luggage, with the Rio interfaces and cables in a separate case. This will be really attractive for touring acts and will allow for plenty more great live albums.

HANDY NEW TOOLS

Yamaha has included some great tools that speed up workflow — Graphic EQ on faders, sends on faders and customisable grouping of input channels, along with user configurable buttons and knobs. ‘Touch & Turn’ is a fabulous new feature that allows a user assigned knob to be instantly associated with any knob touched on the touch screen. Another new feature is that mute groups can now be configured as ‘dimmer groups’. It’s a one-button solution to instantly reduce the level of included channels by a pre-programmed amount.

The feel of this console, the new faders, control knobs and touch screen all have a positive fast and sensitive analogue touch, which is a big improvement from Yamaha.

Virtual Circuit Modelling (VCM) technology has allowed Yamaha to present the sound and functionality of Neve Designs’ EQ and compressors as on-board processors along with a bunch of great sounding new processors in the ‘Premium Rack’, along with all our favourite Yamaha digital effects from the past.

There are the equivalent of eight SPX effects units onboard along with eight of the new ‘premium’ effects machines that offer realistic sounding emulations of Pultec EQ, Urei 1176LN and Telectronix LA2A compression, and Neve Portico processors. Rupert Neve has signed off, so he fully approves of these emulations. The sound and functionality of the effects and processors is the best yet from a Yamaha digital console. I really like the tonal colour of the Rev X reverb, and Neve Portico 5033 EQ and 5043 Compressor, while the Dynamic EQ is very powerful. There is also a Waves MY effects card available if you need extra plug-ins.

HOW IT SOUNDS

The overall sound of the console is very neutral to my ears, the new Rio head-amps are certainly better sounding, certainly not thin or harsh sounding even when levels are near maximum. Yamaha has generally been playing catch-up when it comes to the overall sound of their products and with the CL they have managed to make large improvements. The CL will give fans of the Digidesign Venue, Midas Pro and Digico SD digital consoles something else to consider when drafting up a new tour spec. Overall it is a big step forward in digital live sound mixing.

For its purchase price, Yamaha has produced what is currently perhaps the most complete solution available for the control of audio for live performance and live recording. There’s no waiting here for the next version of firmware or software upgrades for all the great features and capacity to operate correctly, seems it’s been sorted already. Yamaha has also signed off on Dante as the world’s preferred system for transmission and control of digital audio. It looks like there is now a clear leader in the digital format competition — good news for this Australian-developed system. It offers great value for the package of capacity and features it supplies.

There is now no requirement for spending a lot of money on extra interfaces to get what you need out of this system. Buy a good selection of mics, DIs and a speaker system and you are in the concert sound business. Sonically the system is the best that Yamaha has offered and can now be considered to sound as good as any digital console currently available. It delivers almost everything required to do world-class live audio production in one efficient and value for money package.
